Extended Delay Fuze
The ID260MF/RD is the flagship fuze in the ID260MF series, delivering extended function delay time of up to 24 hours. The fuze fits in a standard 3” tail fuzewell and features an easily upgradable communication protocol for future weapon systems. The ID260MF/RD has NATO codification and is in operational use worldwide.
Our fuzes are compatible with modern precision-guided bombs such as JDAM, Paveway, and LIZARD, as well as hard penetrator warheads. We take pride in our ability to manufacture and customize fuzes for customers globally, maintaining an outstanding reputation for safety and reliability in aerial munitions technology.
Function delay settings
Arm and function time can be set manually or from the cockpit using RS422 data communication. The fuze features an internal battery for long function delay times.
Technical Specifications |
|
| Arm time | Manual: 4-25 seconds (12 times) Or via RS422 data communication |
| Function delay time | Manual: 0 – 180 milliseconds (6 times) 15 min - 24 hours (6 times) Or via RS422 data communication |
| Fuze power | Air-driven turbine alternator unit |
| Shelf life | 20 years (in original package) |
| Service life | 10 years (in controlled environment) |
| Weapon system compatibility | MK-81, 82, 83, 84 BLU-109,111,113 GBU-10,12,15,24,27,31,32, 38 Spice Lizard Paveway/ Enhanced Paveway JDAM/LJDAM |
| Standard compliance | Fuze safety MIL-STD-1316 Environmental tests MIL-STD-810 Environmental tests MIL-STD-331 |
